Name: KOSO 710E 720E Eccentric PARA SEAL Butterfly Valves with 3620R 6300RB Pneumatic Cylinder Autuators
Brand: Xiangjing (Shanghai) M&E Technology Co., Ltd
SKU: 710E, 720E
Price: 2,725.00 USD
Availability: InStock

Características Galeria Descrição de produto Avaliações e Comentários Peça umas citações

Características

Especificações

Tipo de corpo: Válvula borboleta excêntrica PARA-SEAL

Tamanho do corpo: 3" (80A) ~ 24" (600A)

Classificação do corpo: Classe ANSI 150~300, JIS 10K~20K

Temperatura do fluido: -196°C ~ +500°C

Conexões: Tipo Wafer, Flangeado (RF)

Materiais do corpo: SCPH2/WCB, SCS13A/CR6, SCS14A/CR8F, etc.

Materiais do disco: SCPH2/WCB, SCS13A/CR6, SCS14A/CR8F, etc.

Tratamento de disco: Cromado ou revestido com Stellite

Rangeability: 60° Abertura 25:1, 90° Abertura 50:1

Características de fluxo: Porcentagem igual aproximada

Destacar:

KOSO 710E butterfly valve with pneumatic actuator

720E PARA SEAL butterfly valve with cylinder

3620R pneumatic control valve with eccentric seal

Informação básica

Lugar de origem: Japão

Marca: KOSO

Número do modelo: 710E, 720E

Condições de Pagamento e Envio

Detalhes da embalagem: embalagem de caixa/caixa de madeira

Tempo de entrega: 6-8 semanas

Termos de pagamento: T/T

Habilidade da fonte: 800 grupos pelo ano

Galeria

KOSO 710E 720E Eccentric PARA SEAL Butterfly Valves with 3620R 6300RB Pneumatic Cylinder Autuators

Descrição de produto

KOSO 710E 720E Eccentric PARA SEAL Butterfly Valves with 3620R 6300RB Pneumatic Cylinder Actuators

Product Overview

KOSO 710E and 720E are eccentric PARA SEAL butterfly valves designed for reliable flow control in various industrial processes. Paired with 3620R and 6300RB pneumatic cylinder actuators, they deliver stable performance, tight shut-off, and long service life under high pressure and high temperature conditions. These valves are widely used in power plants, oil and gas, refineries, and petrochemical systems.

Features

Eccentric disc structure reduces friction and extends service life
Metal seated design for excellent high temperature resistance
Wafer and flanged connections for easy installation
Low operation torque and stable flow control
High sealing performance with low leakage rate
Compatible with 3620R and 6300RB pneumatic actuators
Wide size and pressure rating range for versatile use
Strong erosion and corrosion resistance
Suitable for high temperature and high pressure pipelines
Rugged construction for harsh working environments

Technical Specifications

Size range	3" ~ 24"
Pressure class	ANSI Class 150~300, JIS 10K~20K
Temperature range	-196°C ~ +500°C
Connection type	Wafer, Flanged RF
Body material	WCB, CF8, CF8M, etc.
Disc material	Carbon steel, stainless steel with hard facing
Seal type	Metal seal, PARA SEAL structure
Flow characteristic	Approximate equal percentage
Actuator type	3620R, 6300RB pneumatic cylinder actuators
Standards	IEC, ANSI, JIS applicable

Applications

Thermal power plants and boiler systems
Oil and gas production and transportation
Petroleum refineries
Petrochemical and chemical industries
High-temperature steam pipelines
Energy and utility systems
Industrial process automation

FAQ

Q: What is the difference between 710E and 720E?

A: They share similar structure but differ in detailed design and pressure rating for different working conditions.

Q: Can these valves be used at high temperatures?

A: Yes, they can work stably up to +500°C.

Q: Are 3620R and 6300RB actuators suitable?

A: Yes, they are standard matched actuators for stable and fast operation.

Q: What connections are available?

A: Wafer type and flanged type are both available.

Q: Are they suitable for steam service?

A: Yes, they are widely used for high-pressure and high-temperature steam.
