Fisher FieldVue DVC6200 Smart Valve Positioner with HART Communication

1
MOQ
US $1500.00 - 2000.00/ Set
preço
Fisher FieldVue DVC6200 Smart Valve Positioner with HART Communication
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Communication Protocol: 4-20 mA HART
Diagnostics: Yes
Max Outlet Pressure: 145 psig
Operating Temperature: Standard Temperature, High Temperature
Destacar:

Fisher DVC6200 HART valve positioner

,

smart valve positioner with HART

,

pneumatic control valve positioner
Informação básica
Marca: Fisher
Model Number: DVC6200
Documento: xiangjing valve&instrument ...t .pdf
Condições de Pagamento e Envio
Packaging Details: Cardboard box + protection
Delivery Time: 35-60 days
Payment Terms: T/T
Supply Ability: 2000 set per year
Descrição de produto
Fisher FieldVue DVC6200 Smart Valve Positioner

Advanced pneumatic control device designed for precise regulation of industrial valves, including black water angle valves and sliding-stem actuators.

Product Attributes
Attribute Value
Communication Protocol 4-20 mA HART
Diagnostics Yes
Max Outlet Pressure 145 psig
Operating Temperature Standard Temperature, High Temperature
Technical Specifications
Parameter Specification
Input Signal 4-20 mA DC (HART 5/7 compatible)
Pneumatic Output 1/4 NPT, 0.056-29.5 m³/hr (2.1-1100 scfh)
Supply Pressure Range 1.4-5.5 bar (20-80 psig)
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Protection Rating IP66 / NEMA 4X
Communication Protocol HART 5/7, Multi-drop Network
Accuracy ±1% of Travel Span
Hazardous Area Approvals ATEX, IECEx, CSA, FM, Lloyd's Register
Key Features
  • Digital Intelligence: HART communication for remote configuration and monitoring via Fisher ValveLink software.
  • Linkless Feedback System: Reduces mechanical wear in vibratory environments.
  • Self-Diagnostics: Monitors valve stem travel, air pressure, and electronics.
  • Modular Design: Easy component replacement without field wiring disruption.
  • Environmental Resistance: IP66-rated housing for dust, moisture, and extreme temperatures.
  • Energy Efficiency: Low air consumption (≤0.184 m³/hr at 80 psig) cuts operational costs.
Applications
  • Chemical & Petrochemical: Flow control in corrosive settings
  • Power Generation: Steam valve regulation for boiler efficiency
  • Water Treatment: Automation of black water angle valves in wastewater systems
  • Oil & Gas: ESD valve control in offshore platforms
  • Food & Beverage: Hygienic process control for CIP/SIP systems
  • Marine & Offshore: Reliable operation under vibration and saltwater exposure
